SMITHS DETECTION
SMITHS HEIMANN
Smiths Heimann Products Range
Smiths Detection is a world leader in transportation security, notably airport X-ray systems used in the search for illegal and dangerous items or for explosives detection in checked baggage, hand-baggage or on passengers themselves. Our specialist software supply business allows the management of large sensor and video surveillance networks.

Our detection equipment is used by military forces and public service workers who need to be equipped for chemical agent detection and biological warfare agent identification; by staff responsible for airport security, transportation security and critical infrastructure security; by customs officers responsible for contraband detection and cargo security (based on X-ray screening), and by the emergency services

SMITHS DETECTION
HI-SCAN 10080 XCT
HI-SCAN 10080 XCT has qualified under the U.S. Safety Act which encourages companies to develop anti-terrorism technology and sets limited liability for claims related to terrorism. During testing by the Department of Homeland Security XCT demonstrated effectiveness in preventing, detecting, identifying or deterring acts of terrorism.

A dual-energy X-ray line scanner with full 3D volumetric Computed Tomography (CT) imaging and reconstruction, the HI-SCAN 10080 XCT is the next generation high-speed checked baggage explosives detection system (EDS).

SMITHS DETECTION
HI-SCAN 10080 EDX-2is
Screening objects transported in the cargo hold of airplanes has historically represented a major challenge to the aviation industry. The evolution of this requirement to include 100%
inspection of these objects has now become a critical element in maintaining traveler confidence and assuring the future success of the aviation industry.The automatic explosive
detection system HI-SCAN 10080 EDX-2is represents the latest development of the proven Smiths Heimann detection technology. The abilities of the system help meet all equirements existing within a 100% screening environment. Using the latest developments in this sector, the EDX-2is offers major technological innovations with regard to the X-ray generator, the X-ray sensors and automatic image evaluation. Thus the EDX-2is is able to offer the highest detection rate in its class.

SMITHS DETECTION
HI-SCAN 10080 EDTS
Screening objects transported in the cargo hold of airplanes has historically represented a major
challenge to the aviation industry. The evolution of this requirement to include 100% inspection of
these objects has now become a critical element in maintaining traveler confidence and assuring the future success of the aviation industry.The automatic explosive detection system HI-SCAN 10080 EDtS represents the latest development of the proven Smiths Heimann detection technology.
The abilities of the system help meet all requirements existing within a 100% screening environment. Using the latest developments in this sector, the EDtS offers major technological innovations with regard to the X-ray generator, the X-ray sensors and automatic image evaluation. Thus the EDtS is able to offer the highest detection rate in its class.

SMITHS DETECTION
HI-SCAN 100100T-2is
HI-SCAN 100100T-2is is an advancement of the HI-SCAN 100100T, especially designed for screening oversized baggage and bulky freight reaching up to 100 x 100 cm (39 x 39 in.) in size.
The HI-SCAN 100100T-2is is equipped with two generators arranged in a 90° opposition,
thus beaming in two directions (Dual View).

This particular screening mode facilitates reliable inspections of tightly packed objects in one process while shortening inspection times and increasing the effectiveness of the
procedure. Its new, innovative user concept makes it as easy to handle as the single-beam system.
Even with a second beam direction, this new system is compact and highly space-saving.
Due to the low installation height of the HI-SCAN 100100T conveyor belt, the connection of supplementary feed- and/or discharge conveyor systems for heavy freight is simple.

The HI-SCAN 100100T -2is is especially suited to meet the needs and applications of airports, customs facilities, and parcel services.

SMITHS DETECTION
Hi-SCAN 6040-2is
The HI-SCAN 6040 -2is is an advanced dual-view X-ray inspection system for automatic explosive detection at check-points where bags and personal belongings are screened to protect society.It utilizes proven Heimann X-ray technology to automatically detect explosive materials and generate reliable, high quality dual -
view images.

This X-ray system presents a modern, ergonomic design that provides a user friendly interface to make it easier for the operator to identify threats and dangerous or illegal objects, on screen. Its compact footprint means the HI-SCAN 6040-2is
can be installed in areas with restricted space, providing opera-tors with various options to meet their configuration requirements to ensure reliable, efficient throughput of hand luggage.

As the first dual -view system worldwide, the High Resolution version of HI-SCAN 6040-2is has recently obtained Standard 3 Type C, an extended approval as a Liquid Explosive Detection System (LEDS) under the requirements of the European Civil Aviation Conference (ECAC).

SMITHS DETECTION
B-SCAN 16HR-DV FULL BODY SCANNER
TRANSMISSION X-RAY PEOPLE SCREENING
Feature Highlights
- Detect objects concealed internally in or externally on the body
- Contraband and threat detection including; weapon, explosives (plastic and powder), detonators, narcotics, electronic devices, diomand, precious stones/metals and mobile phones.
- High throughput - scan time less than 7 seconds.
- Complete head to toe inspection in one short inspection cycle.
- State of the art image processing software and zoom functions facilitates efficient image evaluation.
- Low radiation dose < 4.5microSivert/hour

SMITHS DETECTION
B-SCAN 16HR-FB FULL BODY SCANNER
TRANSMISSION X-RAY PEOPLE SCREENING
Feature Highlights
- Detect objects concealed internally in or externally on the body
- Contraband and threat detection including; weapon, explosives (plastic and powder), detonators, narcotics, electronic devices, diomand, precious stones/metals and mobile phones.
- High throughput - scan time less than 7 seconds.
- Complete head to toe inspection in one short inspection cycle.
- State of the art image processing software and zoom functions facilitates efficient image evaluation.
- Low radiation dose < 2.0microSivert/hour

SMITHS DETECTION
MMTD Multi Mode Threat Detector
Feature Highlights
• Hand-held, hardened detector for extreme conditions
• Explosives, narcotics and CWA/TIC detection and identification in one instrument
• Simultaneous dual mode detection of explosives and narcotics from a single sample
• Increased range of explosive detection, including optimization for peroxides and taggants
Additional Highlights
• Intuitive, easy to use interface using a Windows® CE based platform
• Remote, unattended operation capability
• Unlimited data storage via SD memory card
• Up to 5 hours of uninterrupted operation with hot-swappable battery
• Integrated USB
• Wi-Fi Ethernet

SMITHS DETECTION
HCVG CARGO SCANNER
COMPACT HIGH ENERGY GANTRY SERIES FOR TRUCKS, CONTAINERS AND AIR CARGO

Feature Highlights
- Inspect loaded trucks, containers and vehicles at entrances to ports, airports and border crossings
- High throughput of up to 25 vehicles per hour
- Steel Penetration up to 400mm (15.7") @ 6 MeV
- Small footprint with low X-ray emission
- Advance technology imaging capability
- viZual provides a high performance imaging capability with organic/inorganic material discrimination and colorization in a single scan

SMITHS DETECTION
HCVP CARGO SCANNER
COMPACT HIGH ENERGY PASS THROUGH SERIES FOR TRUCKS, CONTAINERS AND AIR CARGO

Feature Highlights
- Inspect loaded trucks, containers and vehicles at entrances to ports, airports and border crossings
- High inspection rate with minimal system operators -195 vehicles per hour
- Steel Penetration up to 300mm (11.8") @ 6 MeV
- Small footprint with low X-ray emission
- Advance technology imaging capability
- viZual provides a high performance imaging capability with organic/inorganic material discrimination and colorization in a single scan

SMITHS DETECTION
RespondR CHEMICAL, EXPLOSIVE AND NARCOTIC DETECTOR
The RespondeR RCI (Raman Chemical Identifier) is a superior field-portable Raman spectrometer supported by a 16,500+ RAMAN Spectral library of:

• White Powders
• Explosives
• Nerve & Blister Agents
• Narcotics
• Common Chemicals
• WMDs

Fast, accurate detection and identification of unknown chemicals, makes the RespondeR RCI a critical tool for use by homeland security, HazMat, USAR, bomb squad, and drug enforcement teams.

RespondeR RCI features:
• Only product with wireless communication to HazMatID
• ReachBack 24/7/365 Technical Support
• Lightweight, field portable Raman Spectrometer
• Upgraded 16,500+ spectral database
• Ease-of-operation in Level A gear
• Point-and-shoot capability
• Waterproof and rugged
• Long lasting rechargeable battery

SMITHS DETECTION
eqo Body Scanner
eqo is an innovative solution to people screening. Using its unique flat-panel millimetre-wave technology, this body imaging system offers state of the art imaging and detection capability within a minimal footprint.

The 3D scanning system provides a rapid means of detecting threat objects using its high resolution, real-time, full motion display. Acting as an electronically configurable lens, the panel scans a large cubic volume. This ensures that the person being scanned always remains in focus.

This ‘next-generation’ approach marks the evolution of millimetre-wave people screening from mechanically scanned to electronically steered imaging technology, which offers a reliable and easily serviceable system.

Feature highlights
- High resolution images – provide excellent detection of concealed threats
- Multi material detection; metals, ceramics, plastics, liquids, etc.
- Minimal footprint – allows for easy checkpoint integration
- Live image presentation
- Simple and rapid passenger processing

SMITHS DETECTION
IONSCAN 500DT TRACE DETECTOR
The IONSCAN 500DT fills the growing need of security professionals to have the ability to detect a wide range of substances and to be able to adapt as threats and their needs change. By incorporating two IMS detectors in a single unit, the IONSCAN 500DT is capable of detecting and identifying explosives and narcotics during a single analysis, giving you the ability to detect a broader range of substances while maintaining the high sensitivity and specificity you expect from Smiths Detection.

The IMS detectors in the IONSCAN 500DT are the same as in the IONSCAN 400B, of which over 6000 are in use by aviation security, government and law enforcement agencies, the military and by private security companies.

This dual detector system is ideal for any security application. Aviation security personnel and the military will benefit from the capability to detect a much broader range of explosive substances. Customs, coast guard and border crossing agencies that require the ability to detect both narcotics and explosives from a single sample will be able to execute their duties utilizing one instrument. Facility security professionals will be aided in better protecting access points to commercial buildings, courthouses and correctional facilities, with the ability to detect multiple threats with one instrument.

Feature Highlights
- Simultaneous detection of explosives and narcotics
- Over 40 substances detected and identified in 8 seconds
- Large touch-screen color display
- Internal data storage
Options
- Transportation case

SMITHS DETECTION
IONSCAN 400B TRACE DETECTOR
With billions of US dollars in drug and asset, seizures being made with the assistance of an IONSCAN, and thousands being used at major international airports, by the military and law enforcement agencies, the IONSCAN 400B is the world’s most popular desktop explosives or narcotics trace detector. A simple wipe with a swab over items such as checked or carry-on luggage, portable electronic devices, and packages is all that is necessary to collect a sample, which is then placed into the IONSCAN for analysis. In 8 seconds, the color-coded display presents results to the operator — red for a detection and green for the “all-clear”. If a contraband substance is detected, the specific name is identified on the display. A detection of trace explosives indicates that an explosives device may be present or that the person may have been handling explosive material in preparing a bomb and further investigation is necessary.

Leading aviation organizations, including the FAA/TSA in the United States, Transport Canada, and the BAA in the United Kingdom, have evaluated and approved the IONSCAN for their aviation security needs.

Sample Collection
Proper sample collection is key to the success of any trace detector. The swab sampler provided with every IONSCAN is the most effective sample collector available. The design allows sufficient force to be applied in sample collection without tiring the operator. The long arm of the swab sampler allows the sample to be collected without risk of hand injury to the operator from hidden sharp objects.

Feature Highlights
- Detect and identify over 40 explosive or narcotic substances
- Tested, field-proven instrument
- Used daily by Military, AVSEC, Customs, Corrections and at high-profile facilities
- Simple operation, easy to maintain
Options
- Printer
- Trolley
- Long Life Air Purification Unit (LLAPU)
- DC remote sampler

SMITHS DETECTION
HI-SCAN 10080 EDX-2is IN-LINE BAGGAGE SCANNER
The automatic explosive detection system HI-SCAN 10080 EDX-2is represents the latest advancement of the proven Smiths Heimann EDX technology. By making use of a dual view X-ray system the evaluation process improves dramatically. Amongst others, this allows the operator virtually to ‘look behind’ hidden objects located within the baggage. Using this dual view system, the rate of bags being rejected is considerably reduced. Thus, the need for a re-inspection at further levels is reduced drastically.

Within the proven multi-level method of checked baggage screening, all baggage is screened automatically for explosives by a high-speed Level 1 system, the EDX-2is. Bags cleared by the EDX-2is continue to their determined destination while rejected bags are automatically diverted to a second security level for further inspection. A common configuration of the multi-level approach would be to have images of rejected bags automatically transferred to an operator workstation for visual inspection (Level 2). Should further scrutiny be necessary, images and bag are sent to Level 3.

With the low throughput requirements for Level 3 screeners, multiple technologies exist for this application and implementation will be dependent on the security philosophy of the airport. Automation of the primary inspection process offers the added benefits of reducing both staff requirements and recurring costs.

Feature highlights
- Dual view system
- Approved according to EU regulation 1448/2006 - Standard 2
- Automatic explosives detection system
- System reaches highest rate of detection in its class
- Tunnel opening 100 x 80 [cm] suitable for oversized luggage
- Screening rate of up to 1800 luggage items per hour

SMITHS DETECTION
HI-SCAN 6040aTiX LIQUID EXPLOSIVE SCANNER
HI-SCAN 6040aTiX is the first system to allow automatic explosives detection at security checkpoints. HI-SCAN 6040aTiX uses several, independent multi-energy generators, each of which is connected to its own sophisticated and state-of-the-art X-ray sensor technology.

While the detection performance of HI‑SCAN 6040aTiX is far superior to that of other automatic systems, the rate of false alarms has been considerably reduced with optimised algorithms. Using advanced computer technologies, even complex analyses can be carried out in real-time without hampering usual checkpoint procedures.

The operating concept of the proven HI-SCAN series has been retained, guaranteeing optimum passenger throughput at checkpoints. The two detailed views (Dual View), available to carry out manual analysis, support the quick and reliable evaluation process. HI-SCAN 6040aTiX - increased security through innovative technology.

Feature highlights
- Automatic detection of explosives in carry-on baggage
- Analysis of Zeff and density using independent views
- Maximum baggage throughput / real time evaluation
- Proven, ergonomic operating concept is retained
- Two high-resolution and detailed views (Dual View)
- X-ray generator with optimized spectrum
- High resolution XADA sensor technology
- Fully integratable in networks for system management, archiving, image distribution and TIP functionalities

SMITHS DETECTION
HI-SCAN 6040i HAND LUGGAGE SCANNER
The HI-SCAN 6040i is a newly designed, compact X-ray inspection system with a tunnel opening of 620 mm (24“) wide by 418 mm (16.5“) high. This tunnel size is ideally suited to cabin baggage and other small items in areas with increasing security demands.The Hi-SCAN 6040i is part of the new ProLine system concept, which offers various layout possibilities, thanks to its modular, flexible design.

Online image analysis methods to support the operator's work, and a new man-machine interface configured according to ergonomic requirements, are pointing the way to the future for this kind of system. Innovative technology and a high degree of reliability, make this system an excellent tool for covering sensitive fields of inspection. The equipment offers the operating personnel optimum support in making decisions and reduces inspection times considerably.
Feature highlights
- High-End processor technology
- High-Speed digital signal transmission
- HI-MAT Plus advanced material classification
- High image resolution
- 24 Bit real time image processing
- New ergonomic user interface
- Free programmable priority keys

SMITHS DETECTION
HI-SCAN 6046si HAND LUGGAGE SCANNER
HI-SCAN 6046si is a further development of HI-SCAN 6040i, the most successful X-ray inspection system in its class, with more than 6000 installations worldwide. HI-SCAN 6046si is far more than a conventional X-ray system with a facelift. Crucial technological innovations in X-ray sensor and image processing technologies were part of the R&D process. HI-SCAN 6046si is equipped with an advanced multi-energy X-ray generator, a new generation of electronics, plus a completely novel high resolution detector line. Thanks to this optimised technology, the system demonstrates performance rates not achieved before.

HI-SCAN 6046si produces extremely detailed X-ray images with more than double the number of real, physical pixels. The considerably enhanced image resolution of the scanned objects represents a decisive advantage for image evaluation in security areas. HI-SCAN 6046si additionally has a higher tunnel opening and therefore can scan objects that exceed standard dimensions for hand luggage in the aviation industry. HI-SCAN 6046si - increased security through advanced technology.
Feature highlights
- New X-ray generator with optimised spectrum
- New high resolution XADA sensor technology
- New HiTraX II system platform with extended scope of services
- High resolution image display with doubled resolution
- Up to 37 mm steel penetration
- Wire detectability up to AWG 41
- Fully integratable in networks for system management, archiving, image distribution and TIP functionalities
- Integrated radioactivity sensor (optional)

SMITHS DETECTION
HI-SCAN 7555i BAGGAGE & BULK SCANNER
The HI-SCAN 7555i is a newly designed, compact x-ray inspection system with a tunnel opening of 755 mm (30“) wide by 555 mm ( 22“) high. This tunnel size is ideally suited to screening checked luggage and packages as well as briefcases, handbags and other small items.

The HI-SCAN 7555i is part of the new ProLine system concept, which offers various layout options, thanks to its modular, flexible system design. Online image analysis methods to support the operator's work, and a new man-machine interface configured according to ergonomic requirements, are pointing the way to the future for this kind of system. Innovative technology and a high degree of reliability, make this system an excellent tool for covering sensitive fields of inspection.

The equipment offers operating personnel optimum support in making decisions and reduces inspection times considerably.
Feature highlights
- High-End processor technology
- High-Speed digital signal transmission
- HI-MAT Plus advanced material classification
- High image resolution
- Bit real time image processing
- New ergonomic user interface
- Free programmable priority keys

SMITHS DETECTION
HI-SCAN 9075 BAGGAGE SCANNER
HI-SCAN 9075 is a state-of-the-art X-ray inspection unit for the scanning of objects up to a size of 90 cm x 76 cm (w x h). Due to its design the imaging system is perfectly suited to the scanning of bulky objects, oversized baggage and freight. Heavy objects can be easily placed on the conveyor belt, which is installed at a height of only 35 cm above the ground.

The low installation height of the HI-SCAN 9075 conveyor system facilitates the connection of supplementary feed- and/or discharge conveyor systems for heavy freight. The HI-SCAN 9075 is also available as a mobile unit and as such is well-tried by airports, customs facilities and haulage companies. State-of-the-art HiTraX technology, efficient online image analysis methods as well as an operator interface ergonomically designed to be adapted to the installation conditions make the HISCAN 9075 an ultramodern and efficient instrument for security checks in sensitive areas. HI-SCAN 9075 - the security concept for dealing with oversized baggage and bulky objects.
Feature highlights
- Ideal method of inspecting oversized and bulky freight
- Ease of handling heavy goods via low conveyor belt
- HiTraX technology employing real-time image processing
- HI-MAT Plus: allows improved material classification
- IMS: image data management (optional)
- Ergonomically designed operating console features user-definable key functions
- Integral network interface
- Typical penetration: 30 mm of steel
- High-resolution detector line

SMITHS DETECTION
HI-SCAN 100100T BAGGAGE & BULK SCANNER
HI-SCAN 100100T is a state-of -the art X-ray inspection system for scanning objects up to a size of 100 X 100 cm. The HI-SCAN 100100T is specially designed to meet the needs and applications of airports, customs facilities, transportation operations, carriers, parcel services or wherever high security and total screening of large objects are required. The low installation height of the HI-SCAN 100100T conveyor system facilitates the connection of supplementary feed and/or discharge conveyor systems for heavy freight.
Feature highlights
- Ideal method of inspecting oversized baggage and freight
- Ease of handling heavy goods via low conveyor belt
- Outstanding image quality with new HiTraX electronics
- Wire detectability AWG 38
- New HI MAT Plus technology for better material distinction
- Tunnel size in optimal proportion to entire system
- NEW! Typical penetration: 31 mm of steel

SMITHS DETECTION
HI-SCAN 145180 Palletized Air Freight
The HI-SCAN 145180 has been specially designed to meet the needs and applications of warehouses, carriers, forwarders and couriers for airports (palletized Lower Deck - Cargo). The HI-SCAN 145180 is a low energy (140 kV) X-ray inspection system with tunnel dimensions of 1450 mm (57“) width and 1800 mm (71“) height. It is especially suitable for the inspection of air cargo transported on standard Euro, British or US pallets. As a leading supplier of X-ray inspection systems Smiths Detection provides an efficient, global service network, working fast and reliably.
Feature highlights
- Universal X-ray system for palletized items
- Excellent image presentation (optimized X-ray geometry)
- Outstanding image quality with new HiTraX electronics
- New HI-MAT Plus technology for advanced material distinction
- Typical penetration: 30 mm of steel
- OTS Operator Training System available as option

SMITHS DETECTION
HI-SCAN 150150 Air Freight/Air Cargo Screening
The HI-SCAN 150150 is specially designed to meet the needs and applications of airports, customs facilities, transportation operations, carriers, parcel services or wherever high security and total screening is required. The HI-SCAN 150150 is a compact medium energy (300 kV) X-ray cargo inspection system with tunnel dimensions of 1500 mm (61”) width and 1500 mm (61”) height. It permits the inspection of skeleton containers, pallets, very large pieces of checked luggage, parcels and crates.
Feature highlights
- Universal X-ray system for bulk items
- Excellent image presentation (optimal X-ray geometry)
- Outstanding image quality with new HiTraX electronics
- New HI-MAT Plus technology for better material distinction
- Typical penetration 60 mm of steel
- Large range of applications

SMITHS DETECTION
HI-SCAN 180180 Air Freight/Air Cargo Screening
The HI-SCAN 180180 is specially designed to meet the needs and applications of airports, customs facilities, transportation operations, carriers, parcel services or wherever high security and total screening is required. It is a compact medium energy (300 kV) X-ray cargo inspection system with tunnel dimensions of 1800 mm (71”) width and 1800 mm (71”) height. It permits the inspection of pallets and LD-3 airfreight containers.

Feature highlights
- Universal X-ray system for bulk items
- Excellent image presentation (optimal X-ray geometry)
- Outstanding image quality with new HiTraX electronics
- New HI-MAT Plus technology for better material distinction
- Typical penetration 60 mm of steel
- Large range of applications
